8. U-Net (Super Resolution)
데이터 소개
- portrait 데이터로 유명한 PFCN dataset 사용
이미지는 다음과 같은 것을 보여준다.
- 800 x 600의 사람 portrait 이미지
- 사람 영역에 대한 흑백 portrait 이미지
- pfcn_original
- 원본 800 x 600 이미지들
- pfcn_small
- colab용 100 x 75 이미지들
최종 목표
- 작게 줄인 PFCN 데이터를 이용해 사람 영역 추출
- 코앱에 구글 drive 연동
- 큰 사진을 작게 줄이기
- 이미지에 대한 오토인코더식 접근 방법
전처리
1
2
3
4
5
6
7
8
9
10
"""
데이터 확인 밎 이미지 크기 줄이기
"""
import imageio
import skimage.transform import resize
x = imageio.imread('datasets/pfcn_original/training/00001.png')
x = resize(x, output_shape = (100, 75, 3))
x = resize(x, output_shape = (50, 37, 3))
1
2
3
4
5
6
7
"""
데이터 로드
"""
datasets = np.load('datasets/pfcn_small.npz')
print(list(datasets.keys()))
train_big_images, test_big_images = datasets['train_images'], datasets['test_images']
1
2
3
4
5
6
7
8
9
10
11
12
13
"""
이미지 축소 및 할당
"""
train_small_images = np.array([resize(img, output_shape=(50, 37, 3)) for img in train_big_images])
test_small_images = np.array([resize(img, output_shape=(50, 37, 3)) for img in test_big_images])
print(train_small_images.shape) # (1700, 50, 37, 3)
print(test_small_images.shape) # (300, 60, 37, 3)
plt.imshow(train_small_images[:5].transpose(1, 0, 2, 3).reshape(50, -1, 3))
plt.colorbar()
plt.show()
모델링
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
def conv2d_block(x, channel):
...
def unet_resolution():
inputs = Input(shape = (50, 37, 3))
...
u10 = Conv2DTranspose(filters = 16, kernel_size = 2, strides = 2, padding = 'valid', output_padding = (0, 1))(c9) # 이미지 4배 크게
outputs = Conv2D(filters = 3, kernel_size = 1, acitvation = 'sigmoid')(u10)
return Model(inputs, outputs)
model = unet_resolution()
model.compile(loss='mae', optimizer='adam', metrics=['accuracy'])
hist = model.fit(
train_small_images,
train_big_images,
validation_data = (
test_small_images,
test_big_images
),
epochs = 53,
verbose = 1
)
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
def srcnn():
inputs = Input(shape = (100, 75, 3))
x = Conv2D(filters = 64, kernel_size = 9, activation = 'relu', padding = 'same')(inputs)
x1 = Conv2D(filters = 32, kernel_size = 1, activation = 'relu', padding = 'same')(x)
x2 = Conv2D(filters = 32, kernel_size = 3, activation = 'relu', padding = 'same')(x)
x3 = Conv2D(filters = 32, kernel_size = 6, activation = 'relu', padding = 'same')(x)
x = Average()([x1, x2, x3])
outputs = Conv2D(filters = 3, kernel_size = 5, activation = 'relu', padding = 'same')(x)
model = Model(inputs, outputs)
model.compile(loss = 'mae', optimizer = 'adam', metrics = ['accuracy'])
return model
srcnn_model = srcnn()
srcnn_model.summary()
"""
__________________________________________________________________________________________________
Layer (type) Output Shape Param # Connected to
==================================================================================================
input_6 (InputLayer) [(None, 100, 75, 3)] 0 []
conv2d_38 (Conv2D) (None, 100, 75, 64) 15616 ['input_6[0][0]']
conv2d_39 (Conv2D) (None, 100, 75, 32) 2080 ['conv2d_38[0][0]']
conv2d_40 (Conv2D) (None, 100, 75, 32) 18464 ['conv2d_38[0][0]']
conv2d_41 (Conv2D) (None, 100, 75, 32) 51232 ['conv2d_38[0][0]']
average_4 (Average) (None, 100, 75, 32) 0 ['conv2d_39[0][0]',
'conv2d_40[0][0]',
'conv2d_41[0][0]']
conv2d_42 (Conv2D) (None, 100, 75, 3) 2403 ['average_4[0][0]']
==================================================================================================
Total params: 89795 (350.76 KB)
Trainable params: 89795 (350.76 KB)
Non-trainable params: 0 (0.00 Byte)
__________________________________________________________________________________________________
"""
srcnn_hist = srcnn_model.fit(
train_lr_images,
train_big_images,
validation_data = (
test_lr_images,
test_big_images
),
epochs = 50,
verbose = 1
)
